"Dragonfly Outriggers." Largest working range of any outrigger design. Also, you can easily maneauver outriggers around jobsite obstacles.
Roll-and-Fold Boom.
Closed Circuit Hydraulic Pumps. We use "Closed-Circuit" technology to maximize efficiency while minimizing components. This cuts heat generation to a minimum and makes our booms the smoothest.
Solid-State "Black Box" Cycling. We have the fastest responding system made to minimize surge.
Simplified Electrical Controls. There are only 3 types of relays in the electrical system.
Proportional Remote Control. Both our hard wite and remote controls are proportional and have identical patterns and layouts for easy and safe boom operation.
Ultra-Filtration. REED Boom Pumps have both suction filters AND charge pump filters for the best system protection possible.
High-Force Dual Shift Cylinders. For easy swing-tube movement through stiff concrete columns. Makes for a faster shift and a smoother-running machine.
High-Capacity Hydraulically Driven Oil Cooler. Features Hydraulically-Driven Fan which can be manually overridden to bypass all electrical.
Many Common Hydraulic Hoses. Field-Experienced Engineers designed the layout so you carry less.
Chromed Concrete Cylinders WITH Hydraulic Lubrication. The Hard-Chromed Surface with Hydraulic Lubrication lowers friction. This makes your pistons last much longer.
"Fully-Tapered" "Two-Half" Wear Plate. Fully Tapered Design helps feed stiff/difficult mixes the best.
Externally Mounted Wear Parts. Reduction components are easily accessible on the outside of the hopper. Replaceable by simple Bolt-On design.
Advanced Boom Design. Both our welding technique and our radiused corner designs make our boom the Strongest in the industry.
Dual-Row Rotec Mast-Head Bearing. For greater rigidity between the boom, mast and pedestal. Also for longest life.
Least number of standard 90 ° elbows in the industry. Means you have less pieces to buy, handle and replace.
Standardized Bolt-On Outrigger Jacks. Easy Serviceability and common part make this outrigger jack the best in the business. No shaky "box-design".
Nothing but straight pipe on the boom. No 15°, 30°,45° elbows.
Boom Valve Located on Deck Operator friendly boom valve location for those nasty days.
|
|
